Yamaha - Clavier Synthé­ti­seur Numé­rique Montage M7

Interface de contrôle

• Nombre de touche : 76
• Type : FSX Keyboard
• Aftertouch : Oui

Générateur Sonore

• Générateur sonore : Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise
• Polyphonie maximum : AWM2: 256 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 16 (max.)
• Capacité Multi Timbral : 16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part
• Wave : Preset: 10 GB (when converted to 16-bit linear format), User: 3.7 GB
• Performance : 3369
• Filtres : 18 types
• Effets : Reverb x 12 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands)

Autres

• Controlleurs : Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Ribbon Controller, Control Slider x 8, Knob x 8, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable switch x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch, Ribbon Controller hold switch
• Ecran : 7" TFT Color Wide VGA LCD touch screen, 512 x 64 Full-dot LCD
• Connections : [USB TO DEVICE] x 2, [USB TO HOST], MIDI [IN]/[OUT]/[THRU], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT (BALANCED) [L/MONO]/[R] (6.3 mm, Balanced TRS jacks), ASSIGNABLE OUTPUT (BALANCED) [L]/[R] (6.3 mm, Balanced TRS jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)
• Accessoires : Preset: 128 and more, User: 2,048
• Tempo : 5 - 300
• Format de séquence : MONTAGE original format, SMF formats 0, 1
• Arpégiateur : Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types
• Pattern : 128 Patterns
• Piste de pattern : Séquenceur 16 pistes
• Type d'enregistrement de pattern : Real time replace, Real time overdub
• Morceaux : 128 Chansons
• Pistes de morceaux : Séquenceur 16 pistes, tempo, scene
• Type d'enregistrement de morceaux : Real time replace, Real time overdub, Real time punch in/out

Fonctions

• Interface audio USB : [Sampling Frequency = 44.1 kHz] Input: 6 channels (3 stereo channels), Output: 32 channels (16 stereo channels) [Sampling Frequency = 44.1 kHz - 192 kHz] Input: 6 channels (3 stereo channels), Output: 8 channels (4 stereo channels)

Dimension / poids

• Largeur : 1 244 mm
• Hauteur : 131 mm
• Profondeur : 396 mm
• Poids : 17,6kg
